Vent Sizing Package 2 (VSP2) Calorimetry Testing
Understand runaway reactions and design effective protection
Runaway reactions and thermally unstable materials can escalate rapidly, creating pressure scenarios that standard design assumptions cannot safely address. Without the right data, relief systems may be undersized or designed on incomplete assumptions.
Vent Sizing Package 2 (VSP2) calorimetry, also referred to as VSP2 testing or vent sizing calorimetry, provides the critical data needed to evaluate these scenarios and support pressure relief system design and vent sizing.
What Is VSP2 Calorimetry?
VSP2 is an advanced calorimetric technique used to simulate reactive and runaway conditions under realistic process environments. It measures key parameters such as:
- Pressure rise rate
- Temperature behavior
- Gas generation
- Two-phase flow characteristics
This data is essential for understanding how a reaction behaves under upset or loss-of-control conditions and for designing effective pressure relief systems.
What Does VSP2 Measure?
VSP2 calorimetry generates critical data used in pressure relief design and DIERS-based analysis, including:
- Adiabatic self-heat rate (dT/dt)
Used to quantify reaction kinetics and support Arrhenius-based modeling, including activation energy and frequency factors. - Non-condensable gas generation rate (dP/dt)
Differentiates between vapor pressure and true gas generation, which is critical for accurate vent sizing and two-phase flow modeling. - Adiabatic temperature rise (ΔTad)
Defines the maximum theoretical temperature increase during a runaway reaction. - Onset temperature and thermal stability
Identifies when decomposition begins and supports screening for thermally unstable materials. - Two-phase flow behavior
Essential for DIERS methodology when both vapor and liquid phases contribute to relief system demand.
These parameters form the basis for DIERS-based vent sizing calculations and emergency relief system design.
Advanced modeling and risk parameters
For processes with significant reactive hazards, VSP2 data supports deeper analysis, including:
- Time to Maximum Rate (TMRad) for evaluating reaction urgency
- Self-Accelerating Decomposition Temperature (SADT) for storage and transport risk
- Two-phase flow modeling aligned with DIERS methodology and RAGAGEP expectations
- Application within frameworks from the AIChE DIERS User Group
These parameters provide the foundation for defensible emergency relief system design.
Why VSP2 Testing Matters
Many incidents occur not because hazards were unknown, but because they were not fully characterized under realistic process conditions.
VSP2 testing helps you:
- Quantify the severity of runaway reactions
- Identify worst-case scenarios
- Generate data required for DIERS-based analysis
- Reduce uncertainty in relief system design
- Support safer scale-up and process changes
Why VSP2 provides more reliable data
VSP2 is designed to simulate real process conditions more accurately than many traditional calorimetry methods.
Key features include:
- Low phi-factor calorimetry (≈1.05–1.10) for near-adiabatic conditions
- Thin-walled test cell to minimize heat loss
- Pressure balancing design for accurate gas generation measurement
- High-shear agitation (up to 1,000 rpm)
This agitation capability is critical for immiscible systems and slurries, where poor mixing can create localized hot spots and lead to underpredicted runaway severity.
How VSP2 compares to other calorimetry methods
Selecting the right calorimetry method depends on your stage of development and the level of data required for design decisions.
| VSP2 | ARC | ARSST | Phi-TEC II | |
| Phi-Factor | 1.05–1.10 | 1.5–5.0 | 1.04–1.10 | 1.05–1.10 |
| Sample Volume | 80–120 ml | 5–10 ml | ~10 ml | 10–100 ml |
| Scalability | Direct | Requires correction | Screening | Direct |
| Agitation | Excellent (stirred) | Poor (unstirred) | Moderate | Excellent |
| Pressure Limit | Up to 5,000 psi | 3,000+ psi | 3,000 psi | 2,000 psi |
| Best Use Case | Final ERS design | Thermal screening | Rapid screening | ERS design |
VSP2 Testing For Runaway Reactions and Vent Sizing
VSP2 calorimetry is a critical tool for DIERS methodology and is widely used to support compliance with RAGAGEP for pressure relief system design.
It is specifically used to generate the data required for vent sizing and pressure relief system design in reactive systems.
It is particularly important when:
- Reactions generate gas or vapor rapidly
- Two-phase flow may occur during a runaway event
- Standard assumptions cannot accurately predict pressure behavior
By replicating real process conditions, VSP2 provides defensible data to support engineering decisions and regulatory expectations.
From Data to Protection
VSP2 is not a standalone test. It is part of a broader approach to managing reactive hazards.
The data generated through VSP2 calorimetry is used to design and validate Emergency Pressure Relief Systems that protect equipment, facilities, and people from overpressure events.
When Is VSP2 Testing Needed?
VSP2 testing is typically applied when:
- Reactive chemistry introduces runaway potential
- Existing data is insufficient for relief system design
- Scaling up from lab to production
- Modifying process conditions or formulations
- Evaluating thermally unstable substances
Integrated with reaction hazard testing
VSP2 calorimetry is often performed as part of a broader Chemical Reaction Hazard (CRH) Testing program, which may include complementary techniques such as Accelerating Rate Calorimetry (ARC) to fully characterize reaction behavior.
This integrated approach ensures that relief system design is based on complete, defensible data.
Why DEKRA
DEKRA combines testing, analysis, and consulting to move from hazard identification to practical protection strategies.
- Deep expertise in reactive chemistry and DIERS methodology
- Integrated testing and consulting capabilities
- Data-driven approach to risk reduction
- Support from early-stage development through full-scale operations
Get Started
Get the data you need to understand your process and design efective protection systems.
