Emergency Pressure Relief Systems - DIERS
Failsafe Emergency Pressure Relief Solutions
A well-designed, properly maintained emergency pressure relief system provides cost-effective, reliable protection to process industries at risk for overpressure situations, such as the chemical, pharmaceutical and related sectors. These systems protect reactors, storage tanks, columns, dryers and other process equipment, but must be correctly designed, operated and maintained throughout their lifecycle in order to perform their safety functions successfully.
Our team of specialists has significant expertise in performing emergency pressure relief vent sizing studies for multi-phase and/or reacting systems and can design or offer advice on every aspect of these systems. We integrate the initial hazard assessment and choice of design scenarios with the generation of necessary data in our Chemical Reaction Hazard laboratory. Furthermore, we can undertake the design of appropriate secondary treatment facilities, provide data to enable mechanical engineering calculations to be performed, and can provide complete specifications for the whole emergency relief vent system. Finally, we can provide in-company training courses on emergency pressure relief design tailored to your specific requirements.
As winners of the Safety and Environmental Award of the Institution of Chemical Engineers for our design of a pressure relief system covering multiple vessels in a plant manufacturing a pyrophoric product, our expertise in the field has been formally recognized. You can rely on us for objective, professional advice based on technical principles and best practices.
From DIERS to Vent Sizing and Beyond
Emergency relief systems must be designed specifically for an individual process and installation. Opting for a "standard" size will generally be inadequate, as there are numerous factors to take into consideration. Our approach is methodical, thorough and scientific, starting with a design procedure based on DIERS standards.
Following DIERS, the main components of our emergency relief systems services are as follows:
- Obtain physical, thermal and chemical properties of relieving materials under process and relieving conditions.
- Identify causes of overpressure
- Analyze the condition of the vessel contents at relieving pressure and temperature
- Select the appropriate type of relief device(s)
- Determine reaction forces on relief discharge piping
- Document the design work including all cases evaluated, design alternatives considered, and the reasons for design decisions.
An emergency pressure relief system is a critical safety system designed to protect process equipment from overpressure conditions that could cause equipment failure, fires, explosions, or hazardous material releases. Emergency pressure relief systems are commonly used to protect reactors, storage tanks, columns, dryers, pressure vessels, and other process equipment.
Emergency pressure relief systems provide a critical layer of protection against overpressure events. Effective pressure relief system design allows excess pressure and relieved materials to be managed safely. When properly designed and maintained, these systems provide reliable protection for facilities handling hazardous chemicals, combustible materials, and reactive processes.
Overpressure may result from runaway chemical reactions, external fires, blocked outlets, cooling failures, equipment malfunctions, thermal expansion, utility failures, or process upsets. Emergency relief system design must consider credible overpressure scenarios and determine how the system will safely control excess pressure under each condition.
DIERS stands for the Design Institute for Emergency Relief Systems. Its methodology is used to evaluate overpressure events and design emergency relief systems, particularly for reacting systems and two phase flow scenarios. DIERS consulting helps engineers understand these complex conditions, while DIERS pressure relief methods support the accurate sizing and selection of relief devices.
Pressure relief vent sizing is the engineering process used to determine the required capacity and dimensions of relief devices and vent systems. Accurate pressure relief vent sizing considers the potential overpressure scenario, process conditions, and relieved materials to help ensure that equipment remains protected during an emergency.
Emergency pressure relief systems are commonly used to protect:
- Chemical reactors
- Storage tanks
- Distillation columns
- Dryers
- Pressure vessels
- Process piping systems
- Pharmaceutical manufacturing equipment
A pressure relief system study identifies credible overpressure scenarios, evaluates existing safeguards, determines pressure relief vent sizing requirements, and develops recommendations for improving protection. Pressure relief system consulting may include hazard assessments, process data reviews, relief calculations, equipment evaluations, and emergency relief system design recommendations.
A pressure relief valve is one component within a broader emergency pressure relief system. The complete system may include relief valves, rupture discs, vent piping, collection systems, flare systems, quench systems, and secondary treatment facilities. These components work together to safely relieve pressure and manage discharged materials.
An emergency pressure relief system should be reviewed following significant process changes, equipment modifications, production increases, material changes, or incident investigations. Reviews may also be needed when applicable codes and standards change. Regular evaluations help confirm that the existing pressure relief system design continues to provide adequate protection.
Pressure relief system design can involve complex interactions among chemical reaction kinetics, thermodynamics, fluid mechanics, and heat transfer. Independent specialists can provide objective analysis, advanced modeling, DIERS consulting, and practical recommendations. This expertise can help organizations evaluate complex scenarios and improve their emergency relief system design.
